ES-345 Tri-Burst, Exclusive
Layered maple body with solid maple center block, mahogany neck with Rounded C profile, laurel fretboard, split parallelogram inlays, and 22 frets, gold hardware, Epiphone Alnico Classic PRO pickups, mono Varitone, premium gig bag
The ES-335's better looking sibling joins the Epiphone Inspired by Gibson lineup
The Gibson ES-345 was first introduced in 1959, a year after the introduction of the ES-335, the world’s first semi-hollowbody electric guitar. It bears many similarities to its predecessor but is an upgraded model with some notable differences. This Epiphone ES-345 is an Inspired by Gibson version of the legendary ES-345. It has a 5-ply layered maple body with a solid maple center block that gives the semi-hollowbody ES-345 sustain and feedback resistance that’s more similar to a solidbody guitar while retaining some of the resonance of a hollowbody, making it the best of both worlds. The body features multi-ply top and single-ply back binding. The mahogany neck has a comfortable Rounded C profile and is topped with a bound laurel fretboard. The fretboard has 22 medium jumbo frets and a 12” radius that is equally well-suited to playing first-position chords and lead lines with lots of string bends. The pearloid split parallelogram inlays are one of the defining features of an ES-345 that separate it from the ES-335, as is the gold hardware. Speaking of hardware, the Epiphone ES-345 is equipped with an Epiphone LockTone™ Tune-O-Matic™ bridge and Stop Bar tailpiece. Both are anchored through the top and directly into the maple center block, contributing to the model’s accurate intonation and outstanding sustain. At the other end, the strings cross over a Graph Tech® nut that reduces string friction and helps ensure tuning stability along with the smooth-turning, gold Epiphone Deluxe tuners. The Keystone buttons of the tuners give them a more vintage-correct appearance. This ES-345 has a 60s Kalamazoo-style headstock that is adorned with a mother-of-pearl Epiphone logo and Gibson Crown inlay. For the electronics, it is equipped with a pair of Epiphone’s acclaimed Alnico Classic PRO™ pickups that are wired to individual volume and tone controls. along with a three-way pickup selector switch that lets you use either pickup by itself or combine them in any ratio that you prefer. A 6-position mono Varitone switch provides even more tonal flexibility. Finished in gloss Tri-Burst, the Epiphone ES-345 is a beautiful example of what an ES-345 is all about and is available at an attainable price. A premium gig bag is also included to keep this beauty safe when it’s not in use.
Body Style
ES
Body Shape
ES-345
Body Material
5-ply Layered Maple
Top
5-ply Layered Maple
Back
5-ply Layered Maple
Side
5-ply Layered Maple
Bracing
Spruce
Centerblock
Maple
Binding
3-ply Top, Single Ply Back and Fretboard
Body Finish
Gloss
Profile
Rounded "C"
Scale Length
628.65 mm / 24.75 in
Fingerboard Material
Laurel
Fingerboard Radius
304.8 mm / 12 in
Neck Material
Mahogany
Fret Count
22
Frets
Medium Jumbo
Nut Material
Graph Tech
Nut Width
43.0 mm / 1.692 in
Inlays
Pearloid Split Parallelogram
Joint
Glued In, Set Neck
Finish
Gold
Bridge
LockTone Tune-O-Matic
Tailpiece
LockTone Stop Bar
Tuning Machines
Epiphone Deluxe
Pickguard
5-ply Black ES-345
Truss Rod
Dual Action
Truss Rod Cover
2-ply Black Bell
Control Knobs
Black Top Hat with Gold Insert
Switch Tip
Ivory
Switch washer
Gold (Varitone Washer)
Strap Buttons
2 - Bottom and Back of Heel
Mounting Rings
Black
Pickup Covers
Gold
Neck Pickup
Alnico Classic PRO
Bridge Pickup
Alnico Classic PRO
Controls
2 Volume, 2 Tone, Mono Varitone
Pickup Selector
3-way Toggle
Output Jack
Epiphone 1/4"
Strings Gauge
.010, .013, .017, .026, .036, .046
Case
Premium Gig Bag
Disclaimer: In order to continually improve the design, quality and performance of our products and instruments and to make use of the best materials at all times, Epiphone reserves the right to change specifications without notice.
