SG Modern Figured Purple Burst
Mahogany body, maple cap with AAA figured maple veneer, asymmetrical SlimTaper mahogany neck with ebony fretboard, ProBucker 2 and 3 pickups with coil splitting and phase switch, premium gig bag
Finish: Purple Burst
The SG of the Future
The SG Modern Figured from Epiphone’s Inspired by Gibson™ Collection has the classic SG™ body profile made from mahogany and a 3/4” maple cap with an AAA-figured maple veneer. Powered by a pair of Epiphone’s ProBucker™ humbucker™ pickups with coil-splitting, phase switching, and a treble bleed circuit for a multitude of tones. It also features an ebony fingerboard, asymmetrical SlimTaper™ neck profile, world-class Grover® Locking Rotomatic® 18:1 ratio tuners, Posi-Lok™ strap buttons, and a Graph Tech® NuBone® nut. A premium gig bag is included.
Profile
Asymmetrical Slim Taper
Scale Length
628.65 mm / 24.75 in
Fingerboard Material
Ebony
Fingerboard Radius
304.8 mm / 12 in
Neck Material
Mahogany
Fret Count
24
Frets
Medium Jumbo
Nut Material
Graph Tech
Nut Width
43.0 mm / 1.692 in
Inlays
Pearloid Trapezoid
Joint
Glued In, Set Neck
Body Style
SG
Body Shape
SG
Body Material
Mahogany
Top
3/4" Maple with AAA Flame Maple Veneer
Body Finish
Gloss
Finish
Nickel
Bridge
LockTone Tune-O-Matic
Tailpiece
LockTone Stop Bar
Tuning Machines
Grover Locking Rotomatic with Tulip Button
Truss Rod
Dual Action
Truss Rod Cover
Bell
Control Knobs
Clear Top Hats with Ridge
Switch Tip
Black
Control Covers
Black
Strap Buttons
2 Posi-Lok; Bottom and Back of Heel
Mounting Rings
Black
Pickup Covers
Nickel
Neck Pickup
ProBucker 2
Bridge Pickup
ProBucker 3
Controls
2 Volume (Push/Pull Coil Split), 2 Tone (Push/Pull Phase)
Pickup Selector
3-way Toggle
Output Jack
1/4"
Strings Gauge
.010, .013, .017, .026, .036, .046
Case
Premium Gig Bag
Disclaimer: In order to continually improve the design, quality and performance of our products and instruments and to make use of the best materials at all times, Epiphone reserves the right to change specifications without notice.
